Charging profiles are a rollout control surface
TL;DR: OCPP charging profiles control how much power a charger delivers and when, using four purposes (station max, EVSE default, transaction override, and an EVSE-level max in OCPP 2.0.1), stack levels for priority, and time-bounded schedules. The effective limit at any moment is the most constraining applicable profile, and a charger accepting a profile does not guarantee it enforces it — so validate behavior on real hardware before rollout.
Most teams encounter charging profiles as a protocol feature. Deployers should treat them as a control surface that can either protect a site or destabilize it.
The useful question is not only:
Which charging profile purpose do we use?
It is:
Which system is allowed to set power limits, how do those limits interact, and how do we know the charger is actually enforcing them?
That is what determines whether smart charging works safely in production.
What are charging profiles?
Charging profiles are OCPP's mechanism for controlling how much power a charger delivers and when. They're the building blocks of smart charging — without them, every charger draws maximum power at all times.
A charging profile is essentially a schedule: "Between time A and time B, limit power to X kW." Each profile carries a purpose (its scope), a stack level (its priority), and a schedule made of time-bounded periods. The charger combines every applicable profile into a single effective limit at each moment.
In practice, teams that treat profiles as a configuration detail tend to discover their gaps the hard way: a site trips its main breaker, or a fleet vehicle leaves under-charged because a default profile silently won the resolution. The mental model that holds up in production is scope first, priority second, schedule third.
What are the four OCPP charging profile purposes?
OCPP defines charging profiles by their purpose — the scope at which a limit applies. There are four: a station-wide ceiling, a per-EVSE default, a per-transaction override, and (in OCPP 2.0.1) an EVSE-level max. Picking the wrong purpose is the most common reason a correct-looking limit fails to take effect.
The hierarchy below is the one to keep in your head. Outer scopes constrain inner ones: the station max bounds every EVSE, and an EVSE default is overridden, but never exceeded, by transaction profiles once the station ceiling is accounted for.
┌─────────────────────────────────────────────────────────────┐
│ CHARGING STATION │
│ │
│ ┌────────────────────────────────────────────────────────┐ │
│ │ ChargePointMaxProfile (Purpose 0) │ │
│ │ "The entire station cannot exceed 100 kW" │ │
│ │ │ │
│ │ ┌──────────────────┐ ┌──────────────────┐ │ │
│ │ │ EVSE 1 │ │ EVSE 2 │ │ │
│ │ │ │ │ │ │ │
│ │ │ TxDefaultProfile │ │ TxDefaultProfile │ │ │
│ │ │ (Purpose 1) │ │ (Purpose 1) │ │ │
│ │ │ "Default: 22 kW" │ │ "Default: 22 kW" │ │ │
│ │ │ │ │ │ │ │
│ │ │ ┌──────────────┐ │ │ ┌──────────────┐ │ │ │
│ │ │ │ TxProfile │ │ │ │ TxProfile │ │ │ │
│ │ │ │ (Purpose 2) │ │ │ │ (Purpose 2) │ │ │ │
│ │ │ │ "This session│ │ │ │ "This session│ │ │ │
│ │ │ │ gets 11 kW" │ │ │ │ gets 7 kW" │ │ │ │
│ │ │ └──────────────┘ │ │ └──────────────┘ │ │ │
│ │ └──────────────────┘ └──────────────────┘ │ │
│ └────────────────────────────────────────────────────────┘ │
└─────────────────────────────────────────────────────────────┘
Purpose 0: ChargePointMaxProfile
Scope: The entire charging station.
This is the absolute ceiling. No matter how many EVSEs are active or what their individual profiles say, the total power draw of the station cannot exceed this limit.
When to use it:
- Your building has a fixed grid connection (e.g., 150 kW)
- You need to comply with demand response signals from the grid operator
- Load shedding during peak hours
Example: A parking garage has 200 kW available from the grid. Set ChargePointMaxProfile to 200 kW. Even if 10 chargers each try to draw 22 kW (220 kW total), the station firmware caps total draw at 200 kW.
Purpose 1: TxDefaultProfile
Scope: A specific EVSE (connector group).
This is the default profile applied to every new transaction on that EVSE. If no transaction-specific profile (Purpose 2) is set, this is what governs the session.
When to use it:
- Time-of-day scheduling: lower power during office hours, full power overnight
- Default limits based on connector type: 7 kW for AC, 50 kW for DC
- Seasonal adjustments: different defaults in summer vs winter
Example:
TxDefaultProfile for EVSE 1:
┌──────────────────────────────────────────────────────┐
│ │
│ 22 kW ─── ┐ ┌─── 22 kW│
│ │ │ │
│ 11 kW ─── │──────────────────────────────│ │
│ │ Office hours │ │
│ 7 kW ─── │ (09:00 - 18:00) │ │
│ │ │ │
│ │ │ │
│ ──────────┼──────┬──────┬──────┬────────┼──────── │
│ 00:00 06:00 09:00 18:00 00:00 │
│ │
│ Night: 22 kW │ Morning: 11 kW │ Day: 7 kW │ Eve │
└──────────────────────────────────────────────────────┘
Purpose 2: TxProfile
Scope: A specific, active transaction.
This overrides the TxDefaultProfile for one particular charging session. It's the most granular level of control.
When to use it:
- Fleet priority: "This delivery van must be at 80% by 6 AM — give it maximum power"
- User tiers: premium users get higher power, free tier gets limited
- Dynamic optimization: adjust based on real-time grid prices or solar production
Example: A fleet vehicle plugs in at 22:00 and needs to depart at 05:00. The TxDefaultProfile says 7 kW (office hour remnant), but you set a TxProfile for this specific transaction:
TxProfile for Transaction #4521:
22:00 - 02:00 → 22 kW (charge fast while grid is cheap)
02:00 - 04:00 → 11 kW (grid price increases)
04:00 - 05:00 → 22 kW (final boost before departure)
Purpose 3: ChargePointMaxProfile at EVSE Level (OCPP 2.0.1)
In OCPP 2.0.1, Purpose 3 is reserved for ChargePointMaxProfile at EVSE level. It limits the maximum power for a specific EVSE regardless of active transactions.
This fills a gap from OCPP 1.6 where you could only set a station-wide max (Purpose 0) or per-transaction limits (Purpose 1 and 2), but nothing at the EVSE level.
How do stack levels resolve profile conflicts?
When several profiles of the same purpose apply to one session, the highest stack level wins. OCPP uses stack levels (0-9+) to establish priority within a purpose, while the purpose hierarchy still bounds the result. Stack levels resolve "which TxProfile," not "TxProfile versus the station max."
Higher stack level = higher priority.
Stack Level 3: TxProfile (fleet override) → 22 kW
Stack Level 2: TxProfile (dynamic pricing) → 15 kW
Stack Level 1: TxDefaultProfile (schedule) → 11 kW
Stack Level 0: TxDefaultProfile (base) → 7 kW
─────────────────────────────────────────────────────
Effective limit = highest stack level = 22 kW
BUT: ChargePointMaxProfile says station max = 50 kW
AND: Two EVSEs active, each at 22 kW = 44 kW total
44 kW < 50 kW → OK, both sessions get their requested power
The effective power for any session is:
effective_power = MIN(
ChargePointMaxProfile (remaining capacity),
MAX(all TxDefaultProfiles by stack level),
TxProfile (if set, highest stack level wins)
)
How do profiles stack in a real scenario?
Profiles stack by applying the most constraining limit across every active purpose simultaneously: the station ceiling bounds the sum of all EVSEs, while each session resolves its own TxDefault and TxProfile limits. Here's a real-world scenario with all profile types active:
Station: 100 kW grid connection
EVSE 1: Session A (fleet van, priority)
EVSE 2: Session B (employee car, standard)
EVSE 3: Empty
┌─────────────────────────────────────────────┐
│ ChargePointMaxProfile: 100 kW │
│ │
│ EVSE 1 (Session A) EVSE 2 (Sess B)│
│ ┌───────────────────┐ ┌──────────────┐│
│ │ TxDefault: 22 kW │ │ TxDefault: ││
│ │ TxProfile: 50 kW │ │ 22 kW ││
│ │ (fleet override) │ │ (no override) ││
│ │ │ │ ││
│ │ Effective: 50 kW │ │ Effective: ││
│ │ │ │ 22 kW ││
│ └───────────────────┘ └──────────────┘│
│ │
│ Total: 50 + 22 = 72 kW │
│ Under 100 kW limit ✓ │
└─────────────────────────────────────────────┘
If Session B tried to draw 60 kW (e.g., DC fast charging), the station would cap it at 50 kW (100 kW station max minus 50 kW already allocated to Session A).
How do profile scheduling periods work?
A charging schedule defines power limits over time as a sequence of periods, each taking effect at a fixed offset from the schedule start. Each profile contains a charging schedule made of periods. Each period specifies:
- Start period — seconds from the schedule start
- Limit — power limit in watts (or amps, depending on unit)
- Number of phases — for AC: 1 or 3 phases
Profile: "Night Optimization"
Schedule start: 2026-03-12T18:00:00Z
Duration: 43200 seconds (12 hours)
Unit: Watts
Periods:
┌─────────┬──────────────────┬──────────┐
│ Start │ Time │ Limit │
├─────────┼──────────────────┼──────────┤
│ 0 sec │ 18:00 │ 7,400 W │
│ 7200 │ 20:00 │ 11,000 W │
│ 14400 │ 22:00 │ 22,000 W │
│ 36000 │ 04:00 │ 11,000 W │
└─────────┴──────────────────┴──────────┘
What changed between OCPP 1.6 and 2.0.1 charging profiles?
The profile model is broadly the same across versions, but OCPP 2.0.1 adds EVSE-level max limits (Purpose 3), richer reporting, and a path for vehicle-driven charging needs. If you run OCPP 1.6 and 2.0.1 chargers side by side, plan for the older fleet lacking the EVSE-level ceiling and the newer reporting messages.
| Feature | OCPP 1.6 | OCPP 2.0.1 |
|---|---|---|
| Profile purposes | 0, 1, 2 | 0, 1, 2, 3 |
| Unit | Amps or Watts | Amps or Watts |
| Recurrency | Daily, Weekly | Daily, Weekly |
| Cost optimization | No | Yes (via NotifyEVChargingNeeds) |
| Vehicle needs reporting | No | Yes |
| Profile reporting | GetCompositeSchedule | GetCompositeSchedule + ReportChargingProfiles |
| EVSE-level max | No (only station-wide) | Yes (Purpose 3) |
What are the most common charging profile mistakes?
The most common charging profile mistakes are scope, recurrence, and verification errors — not protocol bugs. Most profile failures we see in the field are not protocol bugs; they are scope, recurrence, or verification mistakes. The charger accepts the message and reports success, yet the power behavior on site differs from what the operator intended. The four patterns below account for the bulk of them.
Setting profiles on the wrong EVSE. In OCPP 1.6, connectorId=0 means the entire station, and connectorId=1 means the first connector. Mixing these up applies profiles at the wrong scope.
Forgetting about recurrence. A daily recurring profile repeats every 24 hours from the start time. If you set a non-recurring profile, it expires after its duration.
Not using GetCompositeSchedule. After setting multiple profiles, use GetCompositeSchedule to see what the charger will actually do. The composite schedule shows the effective power limit at each point in time, accounting for all stacked profiles.
Exceeding stack level limits. Some chargers only support a limited number of stack levels or profiles per EVSE. Check your charger's capabilities.
What should you test before a production rollout?
Before relying on charging profiles in production, test site cap enforcement, scope correctness, stack resolution, schedule boundaries, charger variance, and fallback behavior. Accepting an OCPP SetChargingProfile message is not proof the charger enforces it. Before relying on profiles in a live deployment, verify actual power behavior on the hardware you will ship, across the conditions that matter. In mixed-vendor rollouts the gap between "accepted" and "enforced" is usually where incidents come from. Validate:
- Site cap enforcement Confirm that aggregate station power respects the upstream limit under simultaneous sessions.
- Scope correctness Verify that station-wide, EVSE-default, and transaction-specific profiles are applied where you expect.
- Stack resolution Test overlapping profiles so you know which effective limit wins in practice.
- Boundary behavior Validate schedule transitions, recurrence windows, and overnight changes.
- Charger variance Compare the same profile logic across charger vendors and firmware versions.
- Fallback behavior Check what happens when connectivity to the CSMS or energy-management source is interrupted.
If you cannot pass those tests, your charging-profile strategy is not deployment-ready yet.
Frequently asked questions
What is the most common charging profile mistake?
The most common mistake is applying the right profile at the wrong scope, or assuming an accepted OCPP message guarantees correct enforcement. Teams need to verify actual power behavior on real chargers, not just confirm that SetChargingProfile returned success.
Why do stack levels matter?
Stack levels matter because multiple profiles of the same purpose can apply to one session at once. If teams do not understand which profile wins, they can create unstable or misleading charging behavior in production. Within a purpose, the highest stack level takes priority.
What should operators test before rollout?
Operators should test site caps, per-EVSE defaults, transaction overrides, schedule boundaries, charger-specific behavior, and fallback logic when backend connectivity is degraded. Each of these is a place where "accepted" and "enforced" can diverge across vendors and firmware.
